PZ11A Flush Stainless Steel Wall Mount

PZ11 Surface Plate 70x115 SK1 SK2 SK4
PZ11 Surface Plate 70x115 SK1 SK2 SK4

PZ11A Is for A-Series Key Switches. Stainless Steel Wall Mount option for flush fitting and High Security. Quality 1.2mm stainless steel with vertical grain. The mounting plates are stud welded for switch mounting from the rear.

Fixing holes are made to suit standard electrical plasterboard bracket for simple installation. Can be custom Laser engraved to suit switch positions. Key Switch in photo is not included in the part. The key switch in photo is for display purposes only.

LIW Order Code “PZ11A”
70mm X 115mm

5mm Spacer plates

PC09 5mm Spacer Block SK1 SK2 SK4
PC09 5mm Spacer Block SK1 SK2 SK4

Designed for applications when the Auto Series Key Switch depth is too long.

LIW Order Code “PC09”
40mm W X 70mm H X 5mm D

PZ37 Surface Stainless Steel Wall Mount

PZ37 Surface Plate 75x115 SK1 SK2 SK4
PZ37 Surface Plate 75x115 SK1 SK2 SK4

Stainless Steel Wall Mount option for surface fitting. Quality 1.2mm stainless steel with vertical grain. The mounting plates supplied with 4 x fixing screws and nyloc nuts.

Designed to be used with any of the A Series key switches.

Key Switch in photo is not included in the part. The key switch in photo is for display purposes only.

LIW Order Code “PZ37”
75mm W X 115mm H

PZ38 Horizontal Surface Plate 115x115

PZ38 Surface Plate 115x115
PZ38 Surface Plate 115x115

Stainless Steel Wall Mount option for surface fitting. Quality 1.2mm stainless steel with vertical grain. The mounting plate is supplied with 4 x M3 Fixing bolts and 4 x M3 Nyloc nuts. Designed to be used with any of the A Series key switches. Manufactured to suit standard 22mm hole size push buttons. Fixing holes are made to suit standard electrical plasterboard bracket for simple installation.

Key Switch and Green Button in photo is not included in the part. The key switch and Green Button in photo is for display purposes only.

LIW Order Code “PZ38”
115mm W X 115mm H

PZ39 Vertical Surface Plate 200x75

PZ39 Surface Plate 200x115
PZ39 Surface Plate 200x115

Stainless Steel Wall Mount option for surface fitting. Quality 1.2mm stainless steel with vertical grain. The mounting plate is supplied with 4 x M3 Fixing bolts and 4 x M3 Nyloc nuts.

Designed to be used with any of the A Series key switches. Manufactured to suit standard 22mm hole size push buttons

Key Switch and Green Button in photo is not included in the part. The key switchand Green Button in photo is for display purposes only.

LIW Order Code “PZ39”
115mm W X 200mm H
