AC current	AC21   10 amp 440 volt
	AC23     3    KW
	AC 3     2.2  KW
DC current	Inductive   24v   6  amp
	DC1           24v  10 amp

Electronic Data:  High contact reliability by multi contacts with 1u standard gold contacts and option 35u gold plating
Circuits:  Available with multiple contacts and hundreds of contact arrangements. Finger proof terminals. Terminals take two 1.5mm wires.
Durability:  Switch tested for 1/2 million operations.

Locking Features

Incorporates standard Key Entrance Set Lock cylinders.
Supplied complete with 530 Series compatibly cylinder and two keys.
Cylinder easily removed and re-assembled without risk of the switch falling apart, using our patient design.
May be master keyed into all common lock brands and high security lock systems.
Lazy cam allows for key removal in both off and on positions (EZY 1) Captive key available (EZY 4)

Other Features

Supplied with four fixing points for a high strength mounting
Comes standard with 40 X 70 clip over plastic cover plate (which can be glued down to protect screw fixing.)
Easy to install instructions included with drill template
Mounting options include: Stainless Steel and Surface mount enclosures.
